Picture of product C-5000

Part #:

Model: C-5000

OEM:

Canyon Aeroconnect
Part Number :




C-5000
FEATURES
  • Tactical Communication Control Head
  • Control and independently monitor any combination of up to three of the following Transceivers: RT-5000, RT-7200, RT-9600(F), RT-30, RT-138(F), RT-118, RT-450, and RT-406F
  • 2 microphone and headset ports allow for simultaneous independent operation of 2 radio systems
  • 350 preset channel memories
  • 99 scan group memory
  • DTMF/Pulse dialing
  • Manual frequency selection on each system
  • Front panel programming
  • PC database data port on the front of the unit
  • Multiple radio enhanced modes: Cross-Band Relay, Simultaneous Multi-radio Transmissions, and Repeater
  • All enhanced functions require that multiple radios be connected to C-5000
  • FAA PMA Certified
  • Options:
  • Black or Gray Faceplate
  • NVG Gen III Compatible Display
  • KY-58 Encryption Ready

Base Part Number Configuration: 31300-0A01-BCDE

  • Option A:
    • 1: Black, Standard
    • 2: Black, NVG
    • 3: Black, 60°
    • 4: Gray, Standard
  • Option B:
    • 1: Standard
    • 2: OTAR Encryption Ready
    • 3: KY-58 Encryption Ready
  • Option C, D, E:
    • 1: 0: No Radio Interface Card
    • 2: 1: Flexcomm I/Flitecom Interface Card (Parallel R/T)
    • 3: 2: RT-5000 Interface Card (Serial R/T)
    SPECIFICATIONS
    Power Requirements: 27.5 Vdc Aircraft Power (± 20%) Current Requirements: 0.4 amps to 1.3 amps
    Weight: 3.5 lbs Temperature: -22°F to 140°F (-30°C to +60°C)
    Panel Lighting: 5 Vdc, 5 Vrms and 28 Vdc Standard Display Options: Standard Green or NVG Gen III compatible
    Radio Interfaces: RT-5000, RT-7200, RT-9600(F), RT-30, RT-138(F), RT-450, RT-406F Preset Channel Memory: 350 Channels, 99 Scan Groups
    Part Number Control Head Description:
    31300-0101-1100 Standard, Black, 1 Parallel RT Control
    31300-0101-1110 Standard, Black, 2 Parallel RT Control
    31300-0101-1111 Standard, Black, 3 Parallel RT Control
    31300-0101-1200 Standard, Black, 1 Serial RT Control
    31300-0101-1210 Standard, Black, 1 Serial RT Control, 1 Parallel RT Control
    31300-0101-1211 Standard, Black, 1 Serial RT Control, 2 Parallel RT Control
    31300-0101-1220 Standard, Black, 2 Serial RT Control
    31300-0101-1221 Standard, Black, 2 Serial RT Control, 1 Parallel RT Control
    31300-0101-1222 Standard, Black, 3 Serial RT Control
    31300-0101-1230 Standard, Black, 1 Serial RT Control, 1 Parallel RT Control w/Tones
    31300-0101-1300 Standard, Black, 1 Parallel RT Control w/Tones
    31300-0101-1311 Standard, Black, 1 Parallel RT Control w/Tones, 2 Parallel RT Control
    31300-0101-1330 Standard, Black, 2 Parallel RT Control w/Tones
    31300-0101-2111 Standard, Black, OTAR Encryption, 3 Parallel RT Control
    31300-0101-2200 Standard, Black, OTAR Encryption, 1 Serial RT Control
    31300-0101-2211 Standard, Black, OTAR Encryption, 1 Serial RT Control, 2 Parallel RT Control
    31300-0101-2300 Standard, Black, -02 R/T
    31300-0101-2330 Standard, Black, -02 R/T
    31300-0101-2333 Standard, Black, -02 R/T
    31300-0201-1100 NVG, Black, 1 Parallel RT Control
    31300-0201-1110 NVG, Black, 2 Parallel RT Control
    31300-0201-1111 NVG, Black, 3 Parallel RT Control
    31300-0201-1200 NVG, Black, 1 Serial RT Control
    31300-0201-1210 NVG, Black, 1 Serial RT Control, 1 Parallel RT Control
    31300-0201-1211 NVG, Black, 1 Serial RT Control, 2 Parallel RT Control
    31300-0201-1220 NVG, Black, 2 Serial RT Control
    31300-0201-1222 NVG, Black, 3 Serial RT Control
    31300-0201-1330 NVG, Black, 2 Parallel RT Control w/Tones
    31300-0201-1333 NVG, Black, 3 Parallel RT Control w/Tones
    31300-0201-2200 NVG, Black, OTAR Encryption, 1 Serial RT Control
    31300-0201-2220 NVG, Black, OTAR Encryption, 2 Serial RT Control
    31300-0201-2223 NVG, Black, OTAR Encryption, 2 Serial RT Control, 1 Parallel RT Control w/Tones
    31300-0201-3200 NVG, Black, KY-58 Encryption, 1 Serial RT Control
    31300-0301-1100 60° Display, Black, 1 Parallel RT Control
    31300-0301-1110 60° Display, Black, 2 Parallel RT Control
    31300-0301-1111 60° Display, Black, 3 Parallel RT Control
    31300-0301-1200 60°, Black, 1 Serial RT Control
    31300-0301-1220 60°, Black, 2 Serial RT Control
    31300-0301-1222 60°, Black, 3 Serial RT Control
    31300-0301-3200 60°, Black, KY-58 Encryption, 1 Serial RT Control
    31300-0401-1100 Standard, Gray, 1 Parallel RT Control
    31300-0401-1110 Standard, Gray, 2 Parallel RT Control
    31300-0401-1111 Standard, Gray, 3 Parallel RT Control
    31300-0401-1200 Standard, Gray, 1 Serial RT Control
    31300-0401-1220 Standard, Gray, 2 Serial RT Control
    31300-0401-1222 Standard, Gray, 3 Serial RT Control
    31300-0401-2200 Standard, Gray, OTAR Encryption, 1 Serial RT Control
    31300-0401-3200 Standard, Gray, KY-58 Encryption, 1 Serial RT Control
    31300-1102-1200 Standard, Black, P-25, 1 Serial RT Control
    31300-1102-1204 Standard, Black, P-25, 1 Serial RT Control, Rear Data Loader Connector
    31300-1102-1210 Standard, Black, P-25, 1 Serial RT Control, 1 Parallel RT Control
    31300-1102-1220 Standard, Black, P-25, 2 Serial RT Control
    31300-1102-1224 Standard, Black, P-25, 1 Serial RT Control, Rear Data Loader Connector
    31300-1202-1200 NVG, Black, P-25, 1 Serial RT Control
    31300-1202-1204 NVG, Black, P-25, 1 Serial RT Control, Rear Data Loader Connector
    31300-1202-1210 NVG, Black, P-25, 1 Serial RT Control, 1 Parallel RT Control
    31300-1202-1220 NVG, Black, P-25, 2 Serial RT Control
    31300-1202-1224 NVG, Black, P-25, 2 Serial RT Control, Rear Data Loader Connector
    31300-1202-4204 NVG, Black, P-25, DES Encryption, 1 Serial RT Control, Rear Data Loader Connector
    31300-1202-4224 NVG, Black, P-25, DES Encryption, 2 Serial RT Control, Rear Data Loader Connector



31300-0101-1330
- Flexcomm Control
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
31300-0201-2200
- Flexcomm Control
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
31300-0201-2220
- Flexcomm Control
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
31300-0301-3200
- Flexcomm Control
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
31300-1102-1224
- Flexcomm Control
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
31300-1202-1200-P-12-000
- 31300-1202-1200 Flexcomm II Control Head (NVG)
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
31300-1202-1210-0-11-000
- Comm Management Control (NVG)
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
31300-1202-1224
- Flexcomm Control
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME

Click on a question below to see the answer. If you have a question about this model that is not answered below, please contact questions@seaerospace.com


In relation to NE (New) parts, many OEMs change their prices and availability without any notice to dealers or the industry. Therefore, through the REQUEST or RFQ indication, we ask that customers contact us for the most accurate price and availability.

In relation to SV & OH parts, the used parts aftermarket in the aviation industry is not an infinite supply. It is a dynamic, constantly changing market that is significantly affected by and susceptible to highs and lows in supply and demand. Therefore, although we attempt to, at times, we are unable to predict the exact moment when an item may be available. Once again, through the REQUEST or RFQ indication on our website, we ask that customers contact us for the most current and accurate price and availability.

The CD-5000 control is a simple, smaller design that is used for the Basic models of RT-5000 (P/N 400-015525-0101/-0501 only). The CD-5000 is Pilot ready with basic flip flop operation and requires less training than the C-5000. The CD-5000 is limited in only controlling 1 RT-5000 and does not support room for growth or upgrade abilities.



On the other hand, the C-5000 is meant to be a RT-5000 and system controller, and is compatible with all RT-5000 models. The C-5000 is a larger design and operation is more involved, requiring Pilot training before use. In addition to more capabilities and functions, such as Relay, Repeat & Simulcast, the C-5000 can also control 2 RT-5000s from a single point.

Simply put, if you are looking for basic functions, while only using 1 RT-5000, the CD-5000 is more than adequate for your needs. You can find more detailed information on these systems on their SEA product pages: CD-5000 / C-5000.
