NSN: |
|
OEM: |
Trans-Cal |
Desc: |
Solid State Altitude Encoder to 35K ft. |
Price | Condition | Status | More Info | |
---|---|---|---|---|
REQUEST | NEW OUTRIGHT | REQUEST LEAD TIME |
|
Weight: | 5.9 oz. | Operating Altitude: | -1000' to +30,000' (Available in altitudes from 30,000' up to 100,000') |
Operating Voltage: | 14 or 28 VCD | Operating Current: | 0.270 Amps |
Operating Temperature: | -20° to +70°C | Warm-up Time: | No Warm-up Time: +20°C to +70°C, -20°C to +20°C 30 seconds |
Accuracy: | ± 50' from -1000' to +30,000' |
Part Number | Solid State Altitude Encoder Description: |
---|---|
SSD120-30N | Up to 30,000 Feet |
SSD120-30NE | Up to 30,000 Feet, Hi Temp |
SSD120-35N | Up to 35,000 Feet |
SSD120-35NE | Up to 35,000 Feet, Hi Temp |
SSD120-42N | Up to 42,000 Feet |
SSD120-42NE | Up to 42,000 Feet, Hi Temp |
SSD120-50N | Up to 50,000 Feet |
SSD120-50NE | Up to 50,000 Feet, Hi Temp |
SSD120-62N | Up to 62,000 Feet |
SSD120-62NE | Up to 62,000 Feet, Hi Temp |
SSD120-65N | Up to 65,000 Feet |
SSD120-65NE | Up to 65,000 Feet, Hi Temp |
SSD120-80N | Up to 80,000 Feet |
SSD120-80NE | Up to 80,000 Feet, Hi Temp |
SSD120-100N | Up to 100,000 Feet |
SSD120-100NE | Up to 100,000 Feet, Hi Temp |
SSD120-30N-RS232 | Up to 30,000 Feet, w/RS232 Port |
SSD120-35N-RS232 | Up to 35,000 Feet, w/RS232 Port |
SSD120-42N-RS232 | Up to 42,000 Feet, w/RS232 Port |
SSD120-30N-RS | Up to 30,000 Feet, w/RS232, RS422/485 & 10 Feet Resolution |
SSD120-35N-RS | Up to 35,000 Feet, w/RS232, RS422/485 & 10 Feet Resolution |
SSD120-42N-RS | Up to 42,000 Feet, w/RS232, RS422/485 & 10 Feet Resolution |
SSD120-30N-RS1 | Up to 30,000 Feet, w/RS232, RS422/485 & 1 Foot Resolution |
SSD120-35E-RS1 | Up to 35,000 Feet, w/RS232, RS422/485 & 1 Foot Resolution |
SSD120-42N-RS1 | Up to 42,000 Feet, w/RS232, RS422/485 & 1 Foot Resolution |
Price | Condition | Status |
---|---|---|
REQUEST | NEW OUTRIGHT | REQUEST LEAD TIME |
Click on a question below to see the answer. If you have a question about this model that is not answered below, please contact questions@seaerospace.com
In relation to NE (New) parts, many OEMs change their prices and availability without any notice to dealers or the industry. Therefore, through the REQUEST or RFQ indication, we ask that customers contact us for the most accurate price and availability.
In relation to SV & OH parts, the used parts aftermarket in the aviation industry is not an infinite supply. It is a dynamic, constantly changing market that is significantly affected by and susceptible to highs and lows in supply and demand. Therefore, although we attempt to, at times, we are unable to predict the exact moment when an item may be available. Once again, through the REQUEST or RFQ indication on our website, we ask that customers contact us for the most current and accurate price and availability.
