Part #:

Model: TFM-138D

OEM:

Technisonic

Desc:

Transceiver, 138 - 174 MHz

Part Number :



TFM-138D

FEATURES

  • Airborne VHF FM Transceiver
  • 138-174 MHz in 2.5 kHz steps
  • 12.5 kHz (narrow band) or 25 kHz (wide band) channel spacing
  • Two channel synthesized guard receiver
  • 120 channels of preset memory
  • Scan and priority scan
  • Dedicated AM receiver DF output
  • All available CTCSS tones, DPL/DCS codes
  • PC uploading and downloading
  • Can operate without restriction on any split frequency pair available within the band
  • Function control by a panel mounted 12-button keypad
  • Function identifier and other related data are presented on 48-character, two-line LED matrix display
  • 3.1 lbs, DZUS mounted and self contained
  • Currently being deployed in Canadian Military Search & Rescue helicopters

SPECIFICATIONS
Frequency Range: 138.000 MHz to 174.000 MHz  Tuning Increments:  2.5kHz
Operating Mode: F3E simplex or semi-duplex Channel Spacing:  12.5 or 25 KHz
Memory Positions: 120 Channels Physical Dimensions: Approx. 8" x 3" x 5.75"
Weight: 3.1 lbs Temperature Range:  -45°C to +70°C
Guard Receiver:  2 channels programmed with: Tx/Rx Frequency,
Tx CTCSS or DPL tone, 9 character alpha numeric title
CTCSS Squelch Capability:  All CTCSS tones available
DPL Capability:  All standard codes DTMF Encoder:  All standard DTMF tones
Audio Output:  0.5 Watts to 600 Ohms  Speaker Output:  2.5 Watts into 4 Ohms
Back Lighting:  28V (standard) or 5V (specify)  Display:  Green (standard), red (specify)
Audio Distortion:  5% max. @ 1mV, RF Transmitter RF Power Output:
power requirement: 28.0 Vdc +/- 15%
Part Number: Description:
981086-1 Green Display and 28V back lighting
981086-1 (5V) Green Display and 5V back lighting
981086-2 Red Display and 28V back lighting
981086-2 (5V Red Display and 5V back lighting



981086-1
- Transceiver, 138 - 174 MHz

NSN: 5962-01-057-7910

Price Condition Status
RFQ RFQ RFQ
981086-1 (5V)
- Transceiver, 138 - 174 MHz
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
981086-2 (5V)
- Transceiver, 138 - 174 MHz
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
