Picture of product Mini6

Part #: 102-0403-15-17

Model: Mini6

OEM:

Kelly Mfg.

Desc:

Multifunctional Indicator

Part Number :
Kelly Manufacturing Logo

Mini6

FEATURES

  • Multifunctional Indicator including attitude, heading, altimeter, airspeed, turn & slip, and vertical speed
  • Combines instrumentation of traditional six-pack in one customizable presentation
  • Selectable – Ground Track or Magnetic Heading
  • Easy to Install – completely self-contained
  • Fits standard Cutouts
  • Internal Battery Backup – up to 3 hours
  • Reliable Solid State
  • Fully FAA TSO Certified
  • 2 YEAR LIMITED WARRANTY




SPECIFICATIONS

operating voltage: 9 to 32VDC OPERATING TEMPERATURE RANGE: -20° to +55° C
vertical speed range: ±9000 feet/minute Weight: 8.3 oz.
altitude range: -5000 to 33000 ft. Running Current: 14VDC System 0.35 AMP Max, 28VDC System 0.20 AMP Max
battery life: Up to 3 hours display resolution: 320 x 240 Pixels, LED Backlight, Color LCD
PITCH/ROLL RANGE: ±360° BATTERY BACKUP: Rechargeable LiPO, 3.75 500mAh (1.85 Wh)

mini6

Part Number: Description:
102-0403-15-17 Mini6  Multifunctional Indicator




102-0403-15-17
- Multifunctional Indicator
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME

Click on a question below to see the answer. If you have a question about this model that is not answered below, please contact questions@seaerospace.com


In relation to NE (New) parts, many OEMs change their prices and availability without any notice to dealers or the industry. Therefore, through the REQUEST or RFQ indication, we ask that customers contact us for the most accurate price and availability.

In relation to SV & OH parts, the used parts aftermarket in the aviation industry is not an infinite supply. It is a dynamic, constantly changing market that is significantly affected by and susceptible to highs and lows in supply and demand. Therefore, although we attempt to, at times, we are unable to predict the exact moment when an item may be available. Once again, through the REQUEST or RFQ indication on our website, we ask that customers contact us for the most current and accurate price and availability.

PLEASE NOTE - Publications are for Reference Only
