Picture of product MI-59057-2

Part #: MI-59057-2

OEM:

Honeywell

Desc:

Waveguide Adapter

Part Number :



WX-900
FEATURES
  • Compact stormscope system designed for small aircraft owners
  • Combined processor/display unit with external antenna
  • Selectable Operation in 25, 50 and 100 nmi ranges
  • Stores lightning data in all ranges simultaneously
  • 360° view of surrounding area
  • Clear function to help determine storm intensity and movement
  • Stopwatch timer with start, stop & reset functions
  • Avionics bus monitor
  • Automatic and pilot-initiated self-test programs
  • Self diagnostics with error messages
  • Service menu to facilitate dealer installation and maintenance
  • Indicator mounts in standard 3" inch hole (no tray needed) with 25 pin D-sub connector
  • Fully TSO'd
  • Supertwist LCD display with electroluminescent backlight
  • Does not have heading stabilization capability (WX-950 has heading stabilization when interfaced with hdg source) Click Here to download WX-900 Pilot's Guide



SPECIFICATIONS
Temperature Range: 0-55C (display/processor) -55 to 70C (antenna) Altitude: 25000 ft. max (display/processor) 25000 ft. max (antenna)
Weight: 1.56 lb (display/processor) .92 lb (antenna) Size: 3.37"W x 3.37"H x 7.55"L (display/processor) 1.00"H x 3.45"W x 6.85"L (antenna)
Power Requirements: 10.5-32VDC input, 8W max Display Range: 25,50,100 nmi
TSO: C110a RTCA: DO-160B B4-CA(PKSABMNO)XXXXXXZ(AB)A(AZ)ZAB (display/processor) B4-AA(YJCLM)XSFXXXXXXXXXX (antenna)
Part Number: Description:
78-8060-5960-2 Display/Processor Unit, Waveguide Adapter
78-8060-5970-1 Antenna, Waveguide Adapter
78-8060-5979-2 Antenna Doubler Plate, Waveguide Adapter
78-8060-5977-6 Antenna Gasket, Waveguide Adapter
78-8060-6003-2 Antenna Cable (25 ft. standard with right angle backshell), Waveguide Adapter
78-8060-6004-8 Hardware Package, Waveguide Adapter



MI-59057-2
- WX-900 Waveguide Adapter
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
