NSN: |
6610-01-424-8325 |
OEM: |
Honeywell |
Desc: |
Flight Data Recorder |
FOR REFERENCE ONLY
Form Factor: | 1/2 ATR Long | Recording Capacity: | Min 25 hours at 768 BPS |
Weight: | Approximately 30 lbs | Finish: | International Orange |
Input Power: | 115 Volt/400 Hz, single phase | Input Interface (DFDR): | ARINC 573/717 data stream from remote FDAU |
Input Interace (FDR): | Vertical acceleration, Altitude (2), Airpseed (synchro & pneumatic), Heading (synchro), Marker Beacon, 3 discretes or ARINC 573/717 FDAU input | Input Interface, Extended Channel (FDR): | Same as FDR, plus 7 additional synchro inputs |
Tape Format: | Blocked incremental, bi-phase encoded, w/768 data BITS, preamble, postamble & IRG | Tape Speed: | Recording: incremental 5ips = 0.41ips (net), Playback: 5ips |
Tape Capacity: | 385 feet or 25 hours recording | Number of Tracks: | 8-track bi-directional, sequential |
Connector Index Pin Code: | In accordance with ARINC No. 573/717 | Playback Time: | 30 min. (w/copy recorder), 2 hrs. (sequential track transcription) |
Environmental Conditions: | RTCA DO-160, TSO-C51A | Crash Survivability: | TSO-C51A |
Part Number: | Description: |
---|---|
980-4100-AXUS | Flight Data Recorder |
980-4100-BXUN | Flight Data Recorder |
980-4100-DXUN | Flight Data Recorder |
980-4100-DXUS | Flight Data Recorder |
980-4100-EMUN | Flight Data Recorder |
980-4100-EMXN | Flight Data Recorder |
980-4100-EXUN | Flight Data Recorder |
980-4100-FMUN | Flight Data Recorder |
980-4100-FWUS | Flight Data Recorder |
980-4100-FXUS | Flight Data Recorder |
980-4100-GMUN | Flight Data Recorder |
980-4100-HXUN | Flight Data Recorder |
980-4100-RQUS | Flight Data Recorder |
Click on a question below to see the answer. If you have a question about this model that is not answered below, please contact questions@seaerospace.com
In relation to NE (New) parts, many OEMs change their prices and availability without any notice to dealers or the industry. Therefore, through the REQUEST or RFQ indication, we ask that customers contact us for the most accurate price and availability.
In relation to SV & OH parts, the used parts aftermarket in the aviation industry is not an infinite supply. It is a dynamic, constantly changing market that is significantly affected by and susceptible to highs and lows in supply and demand. Therefore, although we attempt to, at times, we are unable to predict the exact moment when an item may be available. Once again, through the REQUEST or RFQ indication on our website, we ask that customers contact us for the most current and accurate price and availability.
