Picture of product GFS-83

Part #:

Model: GFS-83

OEM:

Garmin

Desc:

Force-Trim Servo

Part Number :




GI 275

FEATURES

  • Force-trim servo that mounts in parallel with aircraft control system
  • Used to set neutral time position for the control system and provides feedback to pilot
  • Capable of providing stability augmentation
  • Contains dual processors that process incoming data via CAN and drives brushless motor to obtain desired aircraft response
  • Dual processors monitor the speed and torque of the output shaft to ensure it does not exceed limitations
  • Interfaces with LRUs using interfaces: 2 CAN ports, 1 trim release input, 2 discrete inputs, 1 discrete output
  • -13 and -14 includes additional interfaces:  2 ACTIVE LO Discrete Inputs, 2 Aircraft Power & 2 AP Disconnect Diode Isolated Power Inputs, 2 ARINC RX, 1 ARINC TX




SPECIFICATIONS

Temperature: -45C to 70C Input Voltage: 28 VDC
Altitude: -15000 to 25000 ft Environmental: RTCA/DO-160F
Software: RTCA/DO-178B Level A
Part Number: Description:
010-01243-00 Catalog PN, dual processors control engagement of drive clutch
010-01243-11 Catalog PN, dual processors but no drive clutch
010-01243-12 Catalog PN, dual processors but no drive clutch, includes secondary CAN pins for daisy chain installation
010-01243-13

Catalog PN, dual processors but no drive clutch, includes secondary CAN pins for daisy chain installation, additional interfaces as above

010-01243-14 Catalog PN, dual processors but no drive clutch, includes secondary CAN pins for daisy chain installation, , additional interfaces as above, high torque

011-03367-00                   Unit only PN, dual processors control engagement of drive clutch
011-03367-11 Unit only PN, dual processors but no drive clutch
011-03367-12 Unit only PN, dual processors but no drive clutch, includes secondary CAN pins for daisy chain installation
011-03367-13 Unit only PN, dual processors but no drive clutch, includes secondary CAN pins for daisy chain installation
011-03367-14

Unit only PN, dual processors but no drive clutch, includes secondary CAN pins for daisy chain installation, high torque




010-01243-00
- Force-Trim Servo
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
011-03367-00
- Force-Trim Servo
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
011-03367-11
- Force-Trim Servo
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
011-03367-12
- Force-Trim Servo
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
011-03367-13
- Force-Trim Servo
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
011-03367-14
- Force-Trim Servo
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
