Picture of product BXP6403-1-(12)

Part #: 0631.582-915

Model: BXP6403-1-(12)

OEM:

Becker Avionics

Desc:

Mode S Transponder (50000 ft)

Part Number :
Becker Logo





BXP6403-1-12

FEATURES

  • Transmit power:– ≥250 W (class 1), – ≥150 W (class 2)
  • Light weight (≤ 0.8 kg)
  • EASA, FCC certificated (ETSO-2C112b, Level 2es)
  • Suited for VFR and IFR operation
  • Supports non-certified ADS-B Out applications
  • BXP6403: 160mm width for panel installation with the dedicated mounting



SPECIFICATIONS
Output Power: 150W, 250W Altitude: 50,000 ft.
Temperature: - 20°C to +55°C Illumination: 14/28 VDC, white
Supply Voltage:  10 VDC - 33 VDC Certification: ETSO-2C112b
Weight: approx. 2.42 lbs Measurements: 1.622" H x 6.279" W x 8.034" D (with address module)
Part Number: Description:
0631.582-915 Mode S Transponder (50000 ft)





0631.582-915
- Mode S Transponder (50000 ft)
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME

Click on a question below to see the answer. If you have a question about this model that is not answered below, please contact questions@seaerospace.com


In relation to NE (New) parts, many OEMs change their prices and availability without any notice to dealers or the industry. Therefore, through the REQUEST or RFQ indication, we ask that customers contact us for the most accurate price and availability.

In relation to SV & OH parts, the used parts aftermarket in the aviation industry is not an infinite supply. It is a dynamic, constantly changing market that is significantly affected by and susceptible to highs and lows in supply and demand. Therefore, although we attempt to, at times, we are unable to predict the exact moment when an item may be available. Once again, through the REQUEST or RFQ indication on our website, we ask that customers contact us for the most current and accurate price and availability.
