Picture of product IFD510

Part #:

Model: IFD510

OEM:

Avidyne

Desc:

WAAS GPS Receiver

Part Number :

avidyne-logo





IFD510

FEATURES

  • GPS only version of the Avidyne IFD540
  • Avidyne’s exclusive Hybrid Touch interface, touchscreen with knobs and buttons, allows you access to any page in the system within two clicks, turns or a simple push of a button
  • Avidyne’s IFD540 provides a plug-n-play touchscreen GPS upgrade for the Garmin GPS500 series
  • Terrain Awareness (SVS-TA) is provided via terrain coloration, providing visual Caution-Warning Alerting System (CAS) alerts and aural alerts terrain hazard awareness and alerting
  • All IFDs, are equipped with Avidyne’s enhanced Synthetic Vision (SVS) for improved situational awareness
  • Standard high, low and grouping symbology is used to clearly depict obstacles on the SVS display
  • 3D Traffic uses standard traffic symbology with traffic depictions indicating relative threat level by their size and relative altitude and bearing
  • All IFDs are equipped with WiFi and Bluetooth capabilities



SPECIFICATIONS

DISPLAY: 4.8" Diagonal w/Touch Screen resolution: Full VGA-640 x 480 pixels
screen: 65,535 Colors, Ultrabright sunlight readable w/ LED Backlighting Dimension: Width: 6.30" (16.0cm), Height: 2.66" (11.7 cm), Depth: 11.00" (27.5 cm) behind panel including connector
weight w/TRAY & CONNECTORS: 7.13 lbs. (3.23 kg) POWER REQUIREMENTS: 11-33 VDC, 4.4A/6.5 Xmit @ 14 vdc, 2.2/4.0A Xmit @ 28VDC
Temperature: Operating Temp: -20°C to +55°C, Short Term Temp: +70°C VHF COM POWER OUTPUT: 10 Watts nominal, Optional 16 Watt (for 28 VDC installations only)
altitude: to 50,000 ft.



Part Number: Description:
700-00182-010 WAAS GPS Receiver
700-00182-011 WAAS GPS Receiver
700-00182-110 WAAS GPS Receiver
700-00182-111 WAAS GPS Receiver
850-00182-011 WAAS GPS Receiver
850-00182-110 WAAS GPS Receiver
850-00182-111 WAAS GPS Receiver



700-00182-010
- GPS (Black Bezel)
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
700-00182-011
- GPS w/ Video (Black Bezel)
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
700-00182-110
- GPS (Gray Bezel)
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
700-00182-111
- GPS w/ Video (Gray Bezel)
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
850-00182-011
- GPS/WIFI/BT/FLTA/SVS/VIDEO, Black
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
850-00182-110
- GPS/WIFI/BT/FLTA/SVS, Gray
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
850-00182-111
- GPS/WIFI/BT/FLTA/SVS/VIDEO, Gray
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST LEAD TIME
