Part #: 8102

Model: ELT-345

OEM:

ACR/Artex

Desc:

Emergency Locator Transmitter

Part Number :
Bendix King logo

ELT 345



FEATURES
  • Automatic Fixed Emergency Locator Transmitter
  • Very cost effective ELT solution, an industry low price for an ELT providing the same quality and performance on which the ARTEX brand was built
  • Designed for a quick and easy first-time or retrofit installation in experimental and general aviation aircraft
  • Single antenna output for emergency transmission on both 406 MHz (Cospas-Sarsat) and 121.5 MHz (local Search & Rescue) frequencies
  • Enhanced position accuracy within 100 meters through a built-in GPS interface (NMEA 0183 or RS 232)
  • Test the ELT and installation with a satellite-based online confirmation test via ARTEX’s proprietary satellite testing service 406Test.com
  • New hermetically sealed G-Switch for increased reliability
  • Aviation grade connectors and cabling included
  • FAA TSO Approved
  • Can be activated manually (via cockpit remote switch or ELT switch) or automatically (the G-Switch senses a 2.3G or greater impact)

 *In order to ship hazardous materials (HAZMAT) the shipper must have HAZMAT certified personnel. SEA will provide HAZMAT paperwork along with proper packaging and labeling for shipments directly to our customers.  If the shipment must be sent to another location such as a freight forwarder, SEA will provide the HAZMAT paperwork to the original ship to address only. Please contact  your freight forwarder prior to ordering to verify that they are HAZMAT certified.  SEA is not responsible for issues that arise if your freight forwarder does not have HAZMAT qualified personnel.

SPECIFICATIONS
Operating Frequencies: 406.040 MHz (± 1 kHz) Emission Designator 16K0GID / 121.5 (± 6.075 kHz) Emission Designator 3K20A3X Output Power: 406MHz: 5W for 24 hours @ -20°C to +55°C, 121.5MHz: 50mW for 50 hours @ -20°C to +55°C
Output Connector: BNC Female Activation: Automatic by 4.5ft/sec G-Switch or Manual
Battery: 6 year Lithium, Replacement Battery (P/N: 8322) Temperature: Operating: -20°C to +55°C Storage: -55°C to +85°C
Self Test: G-Switch enabled 406MHz & 121.5 MHz Power NAV system Low Battery Remote Control: ON/ARM/RESET
Antenna: Black Whip Antenna (P/N: 8324) Mounting Hardware: Mounting Tray & Strap, P/N: 8323 (Universal mounting hole pattern fits 90% of existing ELT hole configurations)
weight with tray: 2.0 lbs measurements: ELT with mounting hardware installed 6.40" L x 2.96"H x 3.78" W
approvals: Cospas-Sarsat, FAA TSO GPS: Built-in GPS Navigational Interface (NMEA 0183 or RS 232)



Part Number: Description:
8102 GA Kit, 23.4" Black Whip Antenna, 2-Wire Std Remote Switch
8107 GA Kit, 15" Black Whip Antenna, 2-Wire Std Remote Switch
8108 GA Kit, 15" Black Whip Antenna, Slimline 2-Wire Remote Switch



°C
°C
°C
Serial # 324-07087
Condition NEW
Mods -
Tag Date 11/11/24
Shop ACR Electronics Inc.
Warranty 1 Year
Serial # 324-07088
Condition NEW
Mods -
Tag Date 11/11/24
Shop ACR Electronics Inc.
Warranty 1 Year
8102
- ELT 345 w/ Whip Antenna and Remote Switch
Price Condition Status
$835.00 NEW OUTRIGHT 2 IN STOCK
8101
- ELT Base Pack
Price Condition Status
$715.00 NEW OUTRIGHT REQUEST LEAD TIME
8107
- ELT Compact Kit, 15" Whip, Standard Switch
Price Condition Status
$960.00 NEW OUTRIGHT REQUEST LEAD TIME
8108
- ELT Compact Kit, 15" Whip, Standard Switch
Price Condition Status
$1,075.00 NEW OUTRIGHT REQUEST LEAD TIME
8100
- A3-06-2880 ELT Transmitter w/ Battery
Price Condition Status
$695.00 NEW OUTRIGHT DUE IN

Click on a question below to see the answer. If you have a question about this model that is not answered below, please contact questions@seaerospace.com

Long messaging transmits longtitude and latitude.  Short messaging does not.


In relation to NE (New) parts, many OEMs change their prices and availability without any notice to dealers or the industry. Therefore, through the REQUEST or RFQ indication, we ask that customers contact us for the most accurate price and availability.

In relation to SV & OH parts, the used parts aftermarket in the aviation industry is not an infinite supply. It is a dynamic, constantly changing market that is significantly affected by and susceptible to highs and lows in supply and demand. Therefore, although we attempt to, at times, we are unable to predict the exact moment when an item may be available. Once again, through the REQUEST or RFQ indication on our website, we ask that customers contact us for the most current and accurate price and availability.
