Picture of product DM N4-45

Part #: DM N4-45

NSN:

5995-00-160-7645

OEM:

L3Harris

Desc:

Antenna

Part Number :
L3Harris Logo

DM N4-45
FEATURES
  • VOR/LOC Antenna
  • Provides superior VOR/ILS systems performance for high-performance aircraft where aerodynamic drag and weight must be held to a minimum
  • Designed to incorporate the latest developments in structural materials but retain the electrical performance expected from a balanced loop VOR/LOC antenna
  • The DM N4-45 is identical in appearance to the DM N4-15, but incorporates a new integrated radiating boot material design for today's environment



SPECIFICATIONS
Frequency Range: 108-118 MHz VSWR: 5.0:1
Polarization: Horizontal Impedance: 50 Ohms
Connectors: TNC female Radiation Pattern: Omnidirectional
Weight: 5.5 lbs Dimensions 6.7" H x 20.8" L (each blade)





DM N25-1 Diagram



Part Number VOR/LOC Antenna Description:
DM N4-45 see details above



DM N4-45
- Antenna

NSN: 5995-00-160-7645

Price Condition Status
RFQ RFQ RFQ
