Part #: 066-4009-00

Model: KN-72

NSN:

5841-01-372-7886

OEM:

BendixKing

Desc:

VOR/LOC Converter

Part Number :


KN-72



FEATURES

  • Remote mounted VOR/LOC converter for use with KN-53 NAV and KX-155 NAV/COMM
  • Designed to operate with NAV receiver and VOR/LOC indicator to provide OMNI directional range or localizer information
  • Accepts three different VOR composite inputs - .5, .3, 3 VRMS
  • Will provide DC voltages to drive ARINC type indicators
  • Design features include improved VOR scalloping rejecting, versatile mounting, low power consumption, and externally adjustable VOR centering, localizer centering and course width
  • 14 V or 28 V operation
  • TSO'd



SPECIFICATIONS

Size: 1.1"W x 4.0"H x 11.75"L Weight: 1.31 lbs.
TSO (VOR): FAA TSO C40a operation to 45,000 ft.; RTCA DO-114 TSO (LOC): FAA TSO C36c Class D; RTCA DO-131
VOR Accuracy: Bearing error of less than 1.0 deg. with precision track selector LOC Accuracy: Centering error of less than 3ua
Temperature Range: -55 to +71 C (operation) Mounting: Rigid, any position
Course Width (VOR): 150mv deflection for 10 deg. course error Course Width (LOC): 90mv +-5mv deflection for .093ddm 4dB tone ratio
Part Number: Description:
066-4009-00 14 V or 28 V, VOR/LOC Converter



Serial # 17491
Condition SV
Mods 1-3
Tag Date 02/18/22
Shop Southeast Aerospace Inc.
Warranty 6 Months
Serial # 16660
Condition SVC
Mods 1-3
Tag Date 10/28/16
Shop Southeast Aerospace Inc.
Warranty 6 Months
Serial # 8514
Condition OH
Mods 1-3
Tag Date 04/22/16
Shop Southeast Aerospace Inc.
Warranty 6 Months
Serial # 16554
Condition OH
Mods 1-3
Tag Date 12/08/11
Shop Southeast Aerospace Inc.
Warranty 6 Months
Serial # 17325
Condition OH
Mods 1-3
Tag Date 12/08/11
Shop Southeast Aerospace Inc.
Warranty 6 Months
066-4009-00
- VOR/LOC Converter

NSN: 5841-01-372-7886

Price Condition Status
$150.00 SV OUTRIGHT 5 IN STOCK

Click on a question below to see the answer. If you have a question about this model that is not answered below, please contact questions@seaerospace.com


In relation to NE (New) parts, many OEMs change their prices and availability without any notice to dealers or the industry. Therefore, through the REQUEST or RFQ indication, we ask that customers contact us for the most accurate price and availability.

In relation to SV & OH parts, the used parts aftermarket in the aviation industry is not an infinite supply. It is a dynamic, constantly changing market that is significantly affected by and susceptible to highs and lows in supply and demand. Therefore, although we attempt to, at times, we are unable to predict the exact moment when an item may be available. Once again, through the REQUEST or RFQ indication on our website, we ask that customers contact us for the most current and accurate price and availability.

None, they represent the same unit. Original King Radio part numbers were 9 digits. For example, 066-3056-01. During the Bendix and King merger (i.e. Bendix/King), a new part numbering system was created that converted these 9 digit part numbers to 12 digits. Therefore, 066-3056-01 became 066-03056-0001. Despite this numbering change, units that were originally from the King Radio design still have the 9 digit part number format on the unit dataplate. The 12 digit format for King units appears to be used for catalog and internal Honeywell purposes only. Therefore, any unit that has a zero in its third to last number (i.e. XXX-XXXX-X0XX) has a 9 digit part number (i.e. XXX-XXXX-XXX) on its dataplate / ID Plate.
In January 1989 Bendix/King changed from a nine digit to a twelve digit part numbering system. The new, larger 12 digit numbers allowed for the inclusion of software version into the last two digits of the part number for certain units in which software changed frequently such as EFIS and TCAS processors. Therefore, the two digits immediately preceding the software version indicate the hardware version of the unit.

Different software versions imply different operational features and/or interface capabilities and software modifications imply software repairs (bug fixes) to insure proper operation of these features and interfaces. Software version upgrades frequently require hardware modifications to the unit. Such hardware modifications accompanying software version upgrades do not necessarily change the hardware version of the unit.
